Compressor Danfoss Maneurop MTZ56 HL4BVE
General Characteristics
Model number ( on compressor nameplate) MTZ56HL4BVE
Code number for Singlepack* MTZ56-4VI
Code number for Industrial pack* * MTZ56-4VM
Drawing number 8502012g
Suction and discharge connections Rotolock
Suction connection 1-3/ 4 " Rotolock
Discharge connection 1-1/ 4 " Rotolock
Suction connection with supplied sleeve 7/ 8 " ODF
Discharge connection with supplied sleeve 3/ 4 " ODF
Oil sight glass Threaded
Oil equalization connection 3/ 8' ' flare SAE
Oil drain connection None
LP gauge port Schrader
IPR valve 435 psi / 115 psi
Cylinders 2
Swept volume 5.87 in3/ rev
Displacement @ Nominal speed 591 cfh @ 2900 rpm - 713 cfh @ 3500 rpm
Net weight 86 lbs
Oil charge 61 oz, POE - 160PZ
Maximum system test pressure Low Side / High side 363 psi / 435 psi
Maximum differential test pressure 435 psi
Maximum number of starts per hour 12
Refrigerant charge limit 11 lbs
Approved refrigerants R404A, R507A, R134a, R407C
Electrical Characteristics
Nominal voltage 380-400V/ 3/ 50Hz - 460V/ 3/ 60Hz
Voltage range 340-440 V @ 50Hz - 414-506 V @ 60Hz
Winding resistance ( between phases) + / - 7% at 77º F 2.39 #
Maximum Continuous Current ( MCC) 12 A
Locked Rotor Amps ( LRA) 64 A
Motor protection Internal overload protector
Recommended Installation torques
Oil sight glass 37 ft.lbs
Power connections / Earth connection ft.lbs / 1 ft.lbs
Mounting bolts 11 ft.lbs
