ZR108KCE-TFD

Power( Watts) :
Current( Amps) :
EER( Btu/ Wh) :
Mass Flow ( lbs/ hr) : 1280.0
11.6
13.8
7580 5310
11.1
20.0
1325.0
Overall Length( in) :
Overall Width ( in) :
Overall Height ( in) :
11.23
21.0
7.5
7.5
Mounting Height( in) : 21.75*
Mounting Width( in) :
Mounting Length( in) : 10.38
0.0 Stroke ( in) :
106500 88100 Capacity( Btu/ hr) :
Bore Size ( in) : 0.0 Displ( ft^ 3/ hr) : 878.1523
8.721 Displ( in^ 3/ Rev) : 0 Number of Cylinders:
65/ 85 65/ 115
Mechanical Performance
Sound Power( dBA) :
Vibration( mils( peak-peak) ) :
74Ave 79Max
3.0Ave 4.5Max 110
106 Oil Recharge( oz) :
Initial Oil Charge ( oz) :
Discharge Size( in) :
Suction Size ( in) :
132.0 Net Weight( lbs) :
2900
24.2 MCC ( Amps) :
RPM:
LR3104C CSA File No.:
111
LRA-Half Winding:
LRA-High* :
LRA-Low* : 100
UL File Date: 27-Sep-1996
SA-2337 UL File No.:
Electrical
Max Operating Current: 16.8
45/ 100 45/ 130
7/ 8 Stub
1 3/ 8 Stub
Air Conditioning
Evap( ° F) / Cond( ° F)
RG( ° F) / Liq( ° F)
809.0 Internal Free Volume( in^ 3) :
*
HorsePower 9.0
* Low and High refer to the low and high nominal voltage ranges for which the motor is approved.
Overall compressor height on Copeland Brand Product' s specified
mounting grommets.
RLA( = MCC/ 1.4; use for contactor selection) : 17.3
RLA ( = MCC/ 1.56; use for breaker & wire size selection) : 15.5
2007-12-06 Record Date:
Alternate Applications
Application Voltage Phase Refrigerant Frequency( Hz)
460 3 R-134a HFC 60 Air Conditioning
460 3 R-407C HFC 60 Air Conditioning
380/ 420 3 R-134a HFC 50 Air Conditioning
